KN-366Hi Series Automatic Gummed Tape Dispenser

Item NO.: KN-366Hi

Type: Electric (With Heater)

JL3 offers a wide range of water-activated tape dispensers, including manual type and electrical type, which are easy to operate, durable, cost effective and help to improve work efficiency. You are supposed to choose the corresponding type under different working situations.

✔ CE Certified Safety Standards

✔ 12 Programmable Presets (9 Standard + 3 Custom)

✔ Smart Dispensing Auto & IntelliSense Modes

✔ Extended Capacity Supports 1,000 ft Rolls

✔ Assembly Line Integration Port

✔ Smart Alerts Low Water Warning System

✔ High-Precision Cutting within 5mm

Technical Data Sheet

Why Choose JL3® Brand Water-Activated Dispenser?

JL3® Water-Activated Dispenser

JL3’s independently developed tape dispensing and cutting system precisely matches various specifications of water-activated tape application scenarios, providing stable and efficient carton sealing support.

The system offers a combination of tear-type, manual, and automatic types to flexibly adapt to efficiency standards and operational rhythms of various packaging stations.

The Technical Data Sheet of the WAT Dispensers

Model	KN-166	KN-266	KN-366H	KN-366HP	KN-366BHP	KN-366Hi
Type	Pull & Tear	Manual	Electric (Automated)	Battery/Electric (Automated)	Battery/Electric(Automated)	External Battery/Electric(Automated)
With Heater	No	No	Yes	Yes	Yes	Yes
Battery Capacity (mAh)	/	/	/	/	12500	4000 mAh 5600 mAh 6800 mAh
Dispensing Length (cm)	No limit	15-72	No limit	No limit	No limit	No limit
Tape Width (mm)	≤76	≤76	≤76	≤76	≤76	≤76
Tape Diameter (mm)	≤200	≤200	≤200	≤200	≤200	≤250
Cutting Speed（in/s)	/	/	34	47	47	43
Water Bottle Capacity (L)	/	1.3	1.3	1.3	1.3	2.7
Moistening Brushes (pcs)	2	2	2	2	2	1
Operating Voltage (V)	/	/	100-240	100-240	100-240	100-240
Operating Frequency (Hz)	/	/	50-60	50-60	50-60	50-60
N.W (kg)	0.6	8.1	13.4	14.5	15.6	AC Power: 12.1 kg Built-in Battery: 13.8 kg External Battery: 12.1 kg
G.W (kg)	1.0	9.5	15.3	16.3	17.5	AC Power: 15.6 kg Built-in Battery: 16.3 kg External Battery: 14.6 kg
Dimension (mm)	300 x 106 x 120	470 x 275 x 248	510 x 252 x 266	510 x 252 x 266	510 x 252 x 266	510×282×295
Packing Dimension (mm)	360 x 195 x 160	520 x 255 x 295	562 x 317 x 302	562 x 317 x 302	562 x 317 x 302	590x333x360
