JLW-396FR Reinforced Filament Tape

JLW-396FR is a glass fiber cloth tape primarily used in aircraft cargo compartments and other Maintenance, Repair, and Overhaul (MRO) operations. This product is commonly applied to seal aircraft cargo compartment panels, providing an effective seal and easy replacement. In the event of a fire, its wear resistance and flame-retardant properties help isolate the affected area, preventing the spread of fire to other parts of the aircraft. The tape meets all flame retardancy requirements and is made of flame-retardant acrylic adhesive combined with glass fiber cloth, delivering superior product performance and flame resistance.

Product Features

Filament Detail

Application Scenario

Physical Properties	Standard	Metric	Test Method
Reinforcement	Fiberglass Cloth
Adhesive	Acrylic Pressure-Sensitive Adhesive
Backing	PE Film
Color	White And Blue
Total Thickness	7.8 mils	0.20 mm	ASTM D-3652 / GB/T7125
Peel Adhesion 90°	50 oz/in	14 N/25 mm	ASTM D-3330 / GB/T2792
Holding Power	10±2 h	10±2 h	ASTM D-3654 / GB/T4851
Tensile strength	90 lbs/in	400 N/25 mm	ASTM D-3759 / GB/T7753
Elongation at Break	5-7%	5-7%	ASTM D-3759 / GB/T7753
Service Tem.--Mini	23℉	-5℃	BC/BD-220SE
Service Tem.--Max	212℉	100℃	DHG-9055A

Note: All specifications are tested under controlled temperature and humidity conditions (23±2°C, 50±5% RH). Results may vary based on application. Request a free sample to validate performance in your environment.

Our Certification
