JLT-695 Oil Resistant Single Sided Mono Filament Tape

JLT-695 Oil Resistant Single Sided Mono Filament Tape

Item NO.: JLT-695

Backing: PET

Adhesive: Acrylic (Oil Based)

Reinforcement: Fiberglass

Elongation: 3-5%

JLT-695 Backed with PET film and reinforced with glass fiber. It’s high strength mono-directional filament tape with good resistance to abrasion, oil and high temperature. Suitable for transformers, coils and motor parts strapping and fixing.

Safety Data Sheet Technical Data Sheet

Why Choose JL3® Brand Filament Tape?

Core Advantages of JL3® FILAMENT Tape

Combining quality and price
Backed by over a decade of iterative optimization, JL3® delivers quality on par with leading international brands while maintaining strict cost efficiency.
Integrated Solutions
As an integrated enterprise combining manufacturing, R&D, and trading, our dedicated sales team provides precise, customized solutions tailored to your specific packaging requirements.
Rigorous QC
Every shipment undergoes strict quality inspection prior to dispatch to ensure reliable batch consistency and performance stability.
Rapid after-sales response
Standardized after-sales protocol: issues logged within 2 hours, technical response within 24 hours, and definitive resolution within 48 hours.

JLT-695 Reinforced Filament Tape

JLT-695 is a high-strength filament tape based on PET film and fiberglass. It offers excellent abrasion resistance, oil resistance, and high-temperature resistance, making it suitable for bundling and securing components of transformers, coils, and motors.

Product Features

Filament Detail

Application Scenario

Physical Properties	Standard	Metric	Test Method
Reinforcement	Fiberglass
Adhesive	Acrylic Pressure-Sensitive Adhesive
Backing	PET
Color	Clear
Total Thickness	6.3 mils	0.16 mm	ASTM D-3652 / GB/T7125
Peel Adhesion 90°	58 oz/in	16N/25 mm	ASTM D-3330 / GB/T2792
Holding Power	48±5 h	48±5 h	ASTM D-3654 / GB/T4851
Tensile strength	214 lbs/in	950N/25 mm	ASTM D-3759 / GB/T7753
Elongation at Break	3-5%	3-5%	ASTM D-3759 / GB/T7753
Service Tem.--Mini	23℉	-5℃	BC/BD-220SE
Service Tem.--Max	212℉	100℃	DHG-9055A

Note: All specifications are tested under controlled temperature and humidity conditions (23±2°C, 50±5% RH). Results may vary based on application. Request a free sample to validate performance in your environment.
