JLW-306 8*8 Mesh Bi-Directional Filament Tape

Transparent Reinforced Filament Tape. Also Known as Types of Fiberglass, Self Adhesive Reinforced Paper Tape, in Bopp or Pet Film, Adding Glass Fiber or Chemical Fiber Reinforcementm, Can Make The Tape Have Higher Tensile Resistance, and The Improved Synthetic Rubber Adhesive Has Stronger Adhesion, High Wear Resistance and Impact Resistance and High Retention.
  • Brand:

    JL3
  • Item No.:

    JLW-306
  • Color:

    Light Yellow
  • Adhesive:

    Synthetic Rubber
  • Backing :

    PET
  • Reinforcement:

    Fiberglass
  • Product Details

Product Features


Fiberglass Reinforced Packing Tape


JLW-306 is a light yellow and high strength bi-directional filament tape. Glass fiber contributes higher tensile strength and improved synthetic rubber delivers stronger adhesion; generating bi-directionally strengthened effect; high resistance to abrasion; impact resistance and high holding power.



TDS


Physical Properties Standard     Metric Test Method
Reinforcement Fiberglass
Adhesive Synthetic Rubber
Backing PET
Color Light Yellow
Total Thickness 7.9 mils 0.20 mm ASTM D-3652 GB/T7125
Peel Adhesion 90°  137 oz/in 38 N/25mm ASTM D-3330  GB/T2792
Holding Power ≥48h
≥48h ASTM D-3654  GB/T4851
Tensile strength 72 lbs/in 320 N/25mm ASTM D-3759 GB/T7753
Elongation at break 3-5% 3-5% ASTM D-3759  GB/T7753
Service Tem. - Mini 23℉ -5℃ BC/BD-220SE BC/BD-220SE
Service Tem. - Max  158 70 DHG-9055A DHG-9055A



Product Application


Suitable for pipe strapping; general bundling; pallet fixing; sealing and bundling reinforced marine carton.



Fiberglass Reinforced Packing Tape




Other Related Products




· JLW-308: Will be sticky when it is heated; Good wear resistance, applied in the internal fastening of high voltage cable etc.

· JLW-325, JLW-329, JLW-306: Heavy box closure, splicing, general bundling and reinforcing, sealing edge of special woven bag sealing edge, metal coil closure, pipeline bundling etc.

· JLW-2070: Heavy box closure, palletizing, strapping, bundling and reinforcing etc.

· JLW-396FR: Fiberglass cloth tape, is made of flame retardant acrylic adhesive, which provide excellent flame retardant properties ; Mainly designed for the application of aircraft cargo and other maintenance, repair and operating (MRO); It is normally applied in sealing aircraft cargo panels.
