8*8 Mesh Bi-Directional Filament Tape

Thickness: 7.9 mils / Tensile: 72 lbs/in
  • Brand:

    JL3
  • Item No.:

    JLW-306
  • Color:

    Light Yellow
  • Adhesive:

    Synthetic Rubber
  • Backing :

    PET
  • Reinforcement:

    Fiberglass
  • Product Details

Product Features


Fiberglass Reinforced Packing Tape


JLW-306 is a light yellow and high strength bi-directional filament tape. Glass fiber contributes higher tensile strength and improved synthetic rubber delivers stronger adhesion; generating bi-directionally strengthened effect; high resistance to abrasion; impact resistance and high holding power.



TDS


Physical Properties Standard     Metric Test Method
Reinforcement Fiberglass
Adhesive Synthetic Rubber
Backing PET
Color Light Yellow
Total Thickness 7.9 mils 0.20 mm ASTM D-3652 GB/T7125
Peel Adhesion 90°  137 oz/in 38 N/25mm ASTM D-3330  GB/T2792
Holding Power ≥48h
≥48h ASTM D-3654  GB/T4851
Tensile strength 72 lbs/in 320 N/25mm ASTM D-3759 GB/T7753
Elongation at break 3-5% 3-5% ASTM D-3759  GB/T7753
Service Tem. - Mini 23℉ -5℃ BC/BD-220SE BC/BD-220SE
Service Tem. - Max  158 70 DHG-9055A DHG-9055A



Product Application


Suitable for pipe strapping; general bundling; pallet fixing; sealing and bundling reinforced marine carton.



Fiberglass Reinforced Packing Tape




Other Related Products




· JLW-308: Will be sticky when it is heated; Good wear resistance, applied in the internal fastening of high voltage cable etc.

· JLW-325, JLW-329, JLW-306: Heavy box closure, splicing, general bundling and reinforcing, sealing edge of special woven bag sealing edge, metal coil closure, pipeline bundling etc.

· JLW-2070: Heavy box closure, palletizing, strapping, bundling and reinforcing etc.

· JLW-396FR: Fiberglass cloth tape, is made of flame retardant acrylic adhesive, which provide excellent flame retardant properties ; Mainly designed for the application of aircraft cargo and other maintenance, repair and operating (MRO); It is normally applied in sealing aircraft cargo panels.
