Product Features
The E-4 Serie of Tape Dispensers is made for water-activated tape(gummed tape or kraft paper tape) and it is an automatic dispenser, which is suitable for tapes with width range of 36-76mm, 200mm of paper roll diameter, and it automatically dispenses the perfect different length of tape. This dispenser is created for fast-paced packaging environments where increased productivity, efficiency and carton sealing output is needed.
The Technical Data Sheet of the WAT Dispensers
| Model | P-104 | M-204 | E-304H/304HP | E-304BHP | E-304HL | E-404H | E-404HL |
| Type | Pull & Tear | Manual | Electric | Battery/Electric |
Electric |
Electric |
Electric |
| With Heater | No | No | Yes | Yes | Yes | Yes | Yes |
| Battery Capacity (mA) | / |
/ |
/ |
≤12500 |
/ | / | / |
| Dispensing Length (cm) | No limit | 15-75 | No limit |
No limit |
No limit |
No limit |
No limit |
| Tape Width (mm) | ≤76 |
≤76 |
≤76 |
≤76 |
≤76 |
≤76 |
≤76 |
| Tape Diameter (mm) | ≤200 |
≤200 |
≤200 |
≤200 |
≤300 |
≤300 |
≤300 |
| Cutting Speed（cm/s) | / | / | 86/119 |
86/119 |
86 | 86 | 86 |
| Water Bottle Capacity (L) | / | 2.3 | 1.73 | 1.73 | 2.3 | 1.73 | 2.3 |
| Moistening Brushes (pcs) | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| Operating Voltage (V) |
/ |
/ |
100-240 |
100-240 |
100-240 |
100-240 |
100-240 |
| Operating Frequency (Hz) |
/ |
/ | 50-60 |
50-60 |
50-60 |
50-60 |
50-60 |
| N.W (kg) | 0.6 | 8.8 | 12 | 13.4 | 15.2 | 12 | 15.2 |
| G.W (kg) | 1 | 9.8 | 13.4 | 14.8 | 16.8 | 13.4 | 16.8 |
| Dimension (mm) | 300 x 100 x 110 | 470 x 275 x 248 | 510 x 252 x 266 | 510 x 252 x 266 |
550 x 252 x 350 |
550x 252 x 266 | 550 x 252 x 350 |
| Packing Dimension (mm) | 360 x 195 x 160 | 550 x 285 x 285 | 580 x 345 x 335 | 580 x 345 x 335 | 650 x 333 x 400 |
580x 345 x 335 |
650 x 333 x 400 |
